IDM WR300
IDM WR300
The IDM WR300 5G Wireless VPN Transmission Device is a high-speed 5G terminal based on 5G NR/LTE-FDD/LTE-TDD/HSPA+ cellular modems, integrating a dual-core 880MHz CPU, providing 2 10/100/1000M network ports, 1 SIM card slot and LAN port insertion to receive high-speed 5G networks. Its compact design and aluminum housing ensure excellent heat dissipation. The product has also undergone wide temperature, wide voltage input, and electromagnetic compatibility (EMC) testing. It has been widely applied in M2M industries within the IoT chain, such as self-service terminals, smart grid, intelligent transportation, smart home, finance, mobile POS terminals, supply chain automation, industrial automation, intelligent buildings, fire protection, public security, environmental protection, meteorology, digital healthcare, telemetry, military, space exploration, agriculture, forestry, water resources, coal, petrochemicals, and other fields.
I. Product Introduction
The IDM WR300 5G Wireless VPN Transmission Device is a high-speed 5G terminal based on 5G NR/LTE-FDD/LTE-TDD/HSPA+ cellular modems, integrating a dual-core 880MHz CPU, providing 2 10/100/1000M network ports, 1 SIM card slot and LAN port insertion to receive high-speed 5G networks. Its compact design and aluminum housing ensure excellent heat dissipation. The product has also undergone wide temperature, wide voltage input, and electromagnetic compatibility (EMC) testing.
It has been widely applied in M2M industries within the IoT chain, such as self-service terminals, smart grid, intelligent transportation, smart home, finance, mobile POS terminals, supply chain automation, industrial automation, intelligent buildings, fire protection, public security, environmental protection, meteorology, digital healthcare, telemetry, military, space exploration, agriculture, forestry, water resources, coal, petrochemicals, and other fields.
II. Product Features
n MTK dual-core 880MHz CPU;
n 2 x 10/100/1000M Ethernet LAN/WAN interfaces;
n 5G NR/LTE-FDD/LTE-TDD/HSPA+ network;
n Ultra-compact size, with mounting options for rack-mount ear or DIN-rail installation;
n Supports DC 6-30V input voltage.
III. Product Specifications
3.1 Hardware
CPU | MTK Dual-core 880MHz CPU |
RAM | 1Gbit |
NandFlash | 256MB(bytes) |
Operating System | LINUX Latest version |
3.2 Network Interface
Network Interface | ||
Band Support | 5G/4G/3 Version | |
5G | Sub-6G | n1,n2,n3,n5,n7,n8,n12,n20,n25,n28,n40,n41,n66,n71,n 77,n78,n79 |
4G | LTE-FDD | B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29/B30/B32/B66/B71 |
4G | LTE-TDD | B34/B38/B39/B40/B41/B42/B48 |
3G | WCDMA | B1/B2/B3/B4/B5/B8 |
Theoretical Bandwidth | Sub‐6G:Up to 300Mbps,Down to 4Gbps LTE CAT20:Up to 150Mbps,Down to 2.4Gbps HSPA+:Up to 5.76Mbps,Down to 42.0Mbps The above data are theoretical values only, actual network speed is subject to local conditions | |
Routing Functions | ||
Firewall | NAT(NAT) | |
Stateful packet inspection(SPI) | ||
Media Access Control | CSMA/CA with ACK | |
VPN Protocol | PPTP,L2TP ,OpenVPN Client，p2p etc. | |
DHCP | Build-in DHCP (DHCP) | |
Other protocols | Support PPP,PPOE，DDNS,ICMP,VRRP etc. | |
Dual serial server | RS232 Supports transparent transmission or MQTT Custom | |
RS485 Supports transparent transmission or MQTT Custom | ||
3.3 Interface
LAN/WAN Port | 2 x 10/100/1000M Ethernet port |
Reset button | 1x Reset button |
Antenna | 4x 5G Antenna(50Ω SMA Interface) |
LED | SYS---5G |
SIM Card slot | Support 1.8/3.3V SIM Card |
Dual serial port | RS232&RS485 |
Power supply | 3.81*2pin Terminal |
Wide voltage 7~36V | |
Max power consumption 10W |
3.4 Physical Data
Physical specifications | |
Operating temperature | Storage temperature: (-40°C to 85°C) |
Operating temperature: (-40°C to 85°C) | |
Relative humidity | 95%Condensation-free |
Dimensions | 66*27*125mm |
Enclosure material | Aluminum alloy housing |
