Product Overview:

Product Overview:

The S100A-GS series fiber optic Ethernet switch is a switch product developed by our company specifically for building automation, security surveillance, smart city, Tianwang system, electronic police, factory automation and other application environments;

The S100A-GS series provides 1 100Mbps FX fiber optic interface, with SC connector, single-mode/multi-mode, single-fiber/dual-fiber options available. The single-mode model comes standard with a 20KM fiber transmission distance, with optional distances of 40KM/60KM/80KM and up to 200KM also available;

The S100A-GS series provides 8 RJ45 10/100BaseT(X) interfaces, supporting 10Mbps/100Mbps auto-negotiation, full-duplex/half-duplex auto-negotiation, and MDI/MDIX polarity auto-crossover;

The S100A-GS series is specifically designed for front-end data acquisition, transmitting to the central equipment room via gigabit fiber, making it an ideal choice for distributed network access;

This product adopts a high-performance network switching chip, and all ports support non-blocking, wire-speed packet forwarding;

This product features a metal housing that is aesthetically pleasing and sturdy, with an operating temperature of -20°C to 70°C;

This fiber optic Ethernet switch product meets all specifications of CCC, CE/FCC, EN 61000 and other standards. Its high stability and high reliability make it an ideal choice for project applications.

Product Features:

l Gigabit fiber access switch

l Provides 1 1000BaseFX SC fiber optic interface

n Single-mode or multi-mode optional

n Single-fiber or dual-fiber optional

n Transmission distance 20~200 km optional

l Provides 8 100BaseT(X) RJ45 electrical ports

l Provides 8 POE ports optional

n POE complies with IEEE 802.11af and IEEE 802.11at standards

n Maximum power supply capability per POE port >30W

n Non-standard POE version optional

l Complies with IEEE 802.3 standard

l Non-blocking wire-speed forwarding between all ports within the switch

l Supply voltage 5V~30V DC

l Operating temperature -20~70°C, operating humidity 5%~95% non-condensing

Technical Specifications:

Item	Specification	Remarks
Data Ports
Interface	1 x 1000Base FX
Interface	S109A-GS：8 x 10/100MbpsT(X)
Data Rate	10/100/1000Mbps
Switching Parameters
Communication Standard	Compliant withIEEE 802.3 standard
MAC Address Table	8Kbps
Switching Latency	<1us
Packet Buffer	1Mbps
Switching Mechanism	Store-and-Forward
LEDIndicator
Power	Power LED
Interface	Link/Act, Speed
Connector Types
Optical Port	SC
Electrical Port	10/100/1000BaseT(X) RJ45
Power Connector	2.1 x 5.5mm DC Power Jack
Optical Port Parameters
Optical Port Type	SFP Optical Module
Transmission Distance	20KM,40KM,60KM,80KM, 120KM, 200KM
Electrical & Mechanical Characteristics
Power Input	DC 5V~30V
Power Consumption	S109A-GS：4.5W
Housing	Metal Housing
Dimensions (W x H x D)	S109A-GS：132mm x 32mm x 86mm
Weight	S109A-GS：0.55KG
Mounting Method	Wall Mount
Operating Environment
Operating temperature	-20°C ~ 70°C
Storage Temperature	-40°C ~ 85°C
Operating Humidity	5% ~95% (Non-condensing)
