IDM MCC600 Smart Telephone Terminal

I. Overview

The IDM MCC600 Smart Telephone Terminal is an intelligent touchscreen communication terminal that combines a large touchscreen with a traditional telephone handset, integrating the calling functions of a conventional phone with multiple features of modern smart devices. Equipped with a 15.6-inch large touchscreen, users can perform various operations via the touch interface. It comes with a traditional telephone handset, allowing users to make phone calls comfortably.

II. Product Specifications

u 2.0G quad-core CPU, 2G+16G storage;

u 15.6-inch 1920*1080P high-resolution display;

u Ten-point capacitive touchscreen input, as well as computer keyboard and mouse input;

u Audio output: dual 10W full-range speakers, telephone handset output, 3.5mm jack output;

u Audio input: 3.5mm headset interface, telephone handset connection, condenser microphone interface, camera digital microphone input;

u HDMI output for 4K HD video;

u 2 dry contact (switch) interfaces;

u Gigabit Ethernet interface;

u PSTN telephone interface and SIP telephone interface;

u Supports point-to-point voice calls; supports voice conferencing for ≥20 parties;

u Large-capacity contact management function, storing no less than 200 contacts;

u Supports external keyboard and mouse.

III. Features

u Voice Telephony: Supports PSTN and IP telephony, ensuring calls can still be made over traditional telephone lines during power outages, guaranteeing uninterrupted communication at critical moments.

u HD Video Calling: Built-in HD camera paired with a high-resolution display supports clear and smooth video calls, suitable for personal or business communication.

u Video Conferencing: Supports 4-party video conferencing on a single unit; when paired with an MCU device, it can support more parties, delivering an excellent meeting experience; supports one-click meeting setup in simple mode, ready to use on demand; allows participation in hybrid meetings via terminal phone, voice intercom modules, and corresponding surveillance feeds.

u Video Intercom: Combined with IoT control, supports video intercom functionality, suitable for access control, visitor reception, and other scenarios. Supports two-way visible full-duplex intercom, with handset, hands-free, and external intercom modes.

u Recording and Video Recording: Supports audio and video recording during video or voice calls, suitable for meeting minutes, visitor management, and other applications. Supports pre-recorded audio and file broadcasting, allowing local audio files or recordings to be broadcast to designated terminals.

u Supports video linkage, enabling simultaneous display of multiple surveillance camera video feeds on the same screen.

u Supports intercom with designated target terminals in the system via dialing, numeric keypad, or touch selection; supports broadcast paging and monitoring to individual terminals, zones, or the entire area.

u Supports customizable physical emergency button for one-key broadcast to the entire area, enabling one-key emergency paging.

u Supports intercom call log and caller ID display, allowing review of all intercom records.

IV. Applications

u Office Smart Phone

u Command Center Smart Telephone Terminal

u Call Center Smart Telephone Terminal
